Article-No.:
93920
Plug & ShineLED Surface-mounted floor light
Warm white Individual Spot Double light emission, 180°
IP67 3000K 2x3,3W Anthracite
IP67 3000K 2x3,3W Anthracite
- Max. load up to 2000 kg
- IP Protection: IP67 - protected against temporary immersion
- 24 V surface-mounted luminaire
Plug & Shine LED Surface-mounted floor light Warm white Individual Spot Double light emission, 180° IP67 3000K 2x3,3W Anthracite
Plug & Shine surface-mounted lights, made of weather-resistant pressure-cast aluminium, illuminate your paths and driveways without glare, so you can easily find your way after dark. The lights can withstand weights of up to 2,000 kilograms and can be driven over by a car without a problem. The beam angle is 180 degrees. With transformers, connectors and additional lights from the Plug & Shine series, you can compile an individual lighting installation for your outdoor spaces.
- Max. load up to 2000 kg
- IP Protection: IP67 - protected against temporary immersion
- 24 V surface-mounted luminaire
- Glare-free light, directed to the side
- LED lamp (fixed) included in scope of delivery
- Color temperatur: 3000K - Warm white
- Compatible with all accessories in the Plug & Shine series
- Don't forget: Order compatible transformers as well!
- Remember: Order the cable at the same time!
- Can be switched and dimmed via the plug & shine controller (Accessories) using the remote control.
| Dimension | |
|---|---|
| Diameter | 160 mm |
| Dimensions (Height x Width x Depth) | H: 39 mm |
| net weight | 1000 g |
| Design and Material | |
|---|---|
| Form | round |
| Colour | Anthracite |
| Material | Die cast aluminium |
| Installation | |
|---|---|
| Installation site (recommendation) | Floor mounting |
| Application | For glare-free illumination of paths and driveways |
| Energy consumption | |
|---|---|
| Energy efficiency (spectrum A-G) (LED Module) | F |
| Service life | |
|---|---|
| Lifetime | 30000 h |
| Light Characteristics | |
|---|---|
| Nominal luminous flux | 330 lm |
| Color rendering index | > 80 Ra |
| Beam angle | 180 ° |
| Colour temperature | Warm white, 3000 K |
| Luminous flux LED module | 330 lm |
| Lamp Features | |
|---|---|
| Dimming Control | with dimmer |
| Inclusive lamp | yes |
| Component parts | 3,3 W |
| light source property | Light source integrated (non-replacable) |
| Incandescent Equivalent | 53 W |
| Technique | LED |
| Adjustability | fixed |
| Dimmable | Yes |
| IP protection | IP67 |
| Protection class | Protection class III |
| Number of component parts | 2x |
| Maximum load | 2000 kg |
| Replacable | 3 Lightsource is not replaceable, the complete lighting must be replaced. |
| Power consumption | 6 W |
| Voltage | 24 V |
| Voltage type | DC |
| Transformer | |
|---|---|
| apparent power | 6.7 VA |
| Accessories | |
|---|---|
| Radio control included | no |
| Labelling | |
|---|---|
| WEEE-Reg.-No | DE 39236390 |
Downloads
Product data, leaflets & safety instructions
Safety instructionsFlyer Plug & Shine 24V Outdoor System
