Article-No.:
92408
LED Recessed luminaire
Nova Plus 3-piece set
IP65 round 93mm 30° GU10 3x6W 3x460lm 230V dimmable 2700K Gold matt
IP65 round 93mm 30° GU10 3x6W 3x460lm 230V dimmable 2700K Gold matt
- Set of 3 luminaires
- With swivelling spots for ideal illumination
- Incl. replaceable LED lamp
LED Recessed luminaire Nova Plus 3-piece set IP65 round 93mm 30° GU10 3x6W 3x460lm 230V dimmable 2700K Gold matt
The round Nova Plus recessed luminaires (3-piece set) in Gold matt with a replaceable GU10 lamp are suitable for new installations, as well as for replacing existing installations. They can be installed in ceilings with a cavity of only 75 millimetres. Straightforward mounting with retaining springs means that the ceiling remains undamaged, even after repeated installation and removal. The dimming function lets you adjust the brightness according to your needs and emits a warm white work light and cosy mood lighting in one. Thanks to IP65 protection, the luminaire is specially protected against penetration by water jets, making it ideal for installation in wet rooms or outdoor areas.
- Set of 3 luminaires
- With swivelling spots for ideal illumination
- Incl. replaceable LED lamp
- Color temperatur: 2700K - Warm white
- High-quality die-cast aluminium
- IP protection: IP65 – water jet-protected
- The lamp can easily be fitted without a snap ring
- For 230 V direct connection
| Dimension | |
|---|---|
| Dimensions (Height x Width x Depth) | H: 32 mm |
| Diameter | 93 mm |
| Built-in diameter | 83 mm |
| Mounting depth | 45 mm |
| Depth of hollow wall | 30 mm |
| Design and Material | |
|---|---|
| Form | round |
| Colour | Gold matt |
| Material | Aluminium |
| Stainless | stainless alu |
| Energy consumption | |
|---|---|
| Energy efficiency (LED Module) | G |
| Service life | |
|---|---|
| Lifetime | 30000 h |
| Light Characteristics | |
|---|---|
| Colour temperature | Warm white, 2700 K |
| Nominal luminous flux | 460 lm |
| Color rendering index | > 80 Ra |
| Beam angle | 36 ° |
| Lamp Features | |
|---|---|
| Dimmable | with dimmer R+C f.elect.trafos+230V bulbs |
| Inclusive lamp | yes |
| Lamp property | Leuchtmittel enthalten und wechselbar |
| Swivel range | 30 ° |
| Incandescent Equivalent | 40 W |
| IP protection | IP65 |
| Protection class | Protection class II |
| Base/Socket | GU10 |
| Technique | LED |
| Component parts | 6 W |
| Number of component parts | 3x |
| Replacable | 1 Lightsource is replaceable without damage the lighting fixture by enduser. |
| Adjustability | swivelling/tilting |
| Voltage | 230 V |
| Voltage type | AC 50 Hz |
| Accessories | |
|---|---|
| Radio control included | no |
| Labelling | |
|---|---|
| MM symbol | MM symbol |
| WEEE-Reg.-No | DE 39236390 |
