Article-No.:
97753
VDEElectronic Transformer
Mipro AC
max. 35-105W 230/12V 105VA Grey/Black
max. 35-105W 230/12V 105VA Grey/Black
- VDE certificated
- protection class II
- Dimmable with universal dimmer for all transformers (R,L,C)
VDE Electronic Transformer Mipro AC max. 35-105W 230/12V 105VA Grey/Black
Mipro transformers have very compact dimensions and are ideally suited as recessed luminaire systems.
- VDE certificated
- protection class II
- Dimmable with universal dimmer for all transformers (R,L,C)
- Integrated fire protection
- Temperature monitor and electronic fuse
- Can be used at an ambient temperature of up to 50°
| Dimension | |
|---|---|
| Dimensions (Height x Width x Depth) | H: 30 x B: 38 x T: 137 mm |
| Built-in diameter | 45 mm |
| Design and Material | |
|---|---|
| Colour | Black, Grey |
| Material | Plastic |
| Features | |
|---|---|
| Softstart | Softstart |
| Integrated thermal protection | integrated thermal protection |
| Integrated temperature monitor and electronic fuse | Integrated temperature monitor and electronic fuse |
| Service life | |
|---|---|
| Service life, electronic ballast | 50000 h |
| Lifetime | 50000 h |
| Lamp Features | |
|---|---|
| Dimmable | with dimmer R, L, C (universal compatibility) |
| Inclusive lamp | no |
| Lamp property | Ohne Leuchtmittel |
| Maximum wattage range | max. 35-105 W |
| Protection class | Protection class II |
| Technique | Accessories without bulbs |
| Replacable | 7 not concerned. |
| Adjustability | fixed |
| Voltage | 230/12 V |
| Transformer | |
|---|---|
| Integrated fire protection | Integrated fire protection |
| elevated spike protection | elevated spike protection |
| Integrated spark protection | Integrated spark protection |
| integrated overload protection | integrated overload protection |
| Transformer power range | 105 VA |
| Accessories | |
|---|---|
| Radio control included | no |
| Labelling | |
|---|---|
| VDE | VDE certificated |
| MM symbol | MM symbol |
| WEEE-Reg.-No | DE 39236390 |
