Article-No.:
97782
VDE
Electronic Transformer
Flat Halogen AC
max. 35-105W 230/12V 105VA White
max. 35-105W 230/12V 105VA White
- VDE certificated
- protection class II
- Dimmable with universal dimmer for all transformers (R,L,C)
VDE Electronic Transformer Flat Halogen AC max. 35-105W 230/12V 105VA White
Living up to their name, our Flat transformers are particularly flat. Their height of only 24 mm makes them ideal for use with suspended ceilings.
- VDE certificated
- protection class II
- Dimmable with universal dimmer for all transformers (R,L,C)
- Integrated fire protection
- Temperature monitor and electronic fuse
| Dimension | |
|---|---|
| Dimensions (Height x Width x Depth) | H: 24 x B: 50 x T: 147 mm |
| Built-in diameter | 55 mm |
| net weight | 163 g |
| Design and Material | |
|---|---|
| Colour | White |
| Material | Plastic |
| Features | |
|---|---|
| Softstart | Softstart |
| Integrated thermal protection | integrated thermal protection |
| Integrated temperature monitor and electronic fuse | Integrated temperature monitor and electronic fuse |
| Service life | |
|---|---|
| Service life, electronic ballast | 50000 h |
| Lifetime | 50000 h |
| Lamp Features | |
|---|---|
| Inclusive lamp | no |
| light source property | Without light source |
| Technique | Accessories without bulbs |
| Adjustability | fixed |
| Dimmable | with dimmer R, L, C (universal compatibility) |
| Maximum wattage range | max. 35-105 W |
| IP protection | IP20 |
| Protection class | Protection class II |
| Replacable | 7 not concerned. |
| Voltage | 230/12 V |
| Transformer | |
|---|---|
| Transformer power range | 105 VA |
| Integrated fire protection | Integrated fire protection |
| elevated spike protection | elevated spike protection |
| Integrated spark protection | Integrated spark protection |
| integrated overload protection | integrated overload protection |
| Accessories | |
|---|---|
| Radio control included | no |
| Labelling | |
|---|---|
| VDE | VDE certificated |
| MM symbol | MM symbol |
| WEEE-Reg.-No | DE 39236390 |
