Article-No.:
5140
Smart Home Zigbee
Set
LED Recessed luminaire Nova Coin + Zigbee Cephei
swivelling round 84mm 50° Coin 3x6W 3x470lm 230V 2700K matt white
swivelling round 84mm 50° Coin 3x6W 3x470lm 230V 2700K matt white
- Set includes 1x 50043 and 1x 93449
- Usable with smart home gateways that have a Zigbee interface
- Can be controlled with the Smart Home Zigbee remote control
Smart Home Zigbee Set LED Recessed luminaire Nova Coin + Zigbee Cephei swivelling round 84mm 50° Coin 3x6W 3x470lm 230V 2700K matt white
The set comprising three black Nova recessed spotlights and a Cephei switch controller offers smart lighting in an attractive design with high energy efficiency. The minimalistic look of the swivelling recessed spotlights is undisturbed by snap rings: As the lamp is inserted from behind, no snap rings are necessary. Thanks to the 230 V direct connection, the lights can easily be interlinked without any restrictions. With the Cephei Switch Controller you can switch the white recessed spotlights on and off. It is simply fitted between the 230 V connection and the light. The controller is Zigbee 3.0-compatible. Zigbee 3.0 is a radio transmission protocol that interlinks devices from different manufacturers. This allows not only the centralised control of lighting; shutters, heating and alarm systems, for example, can also be integrated.
- Set includes 1x 50043 and 1x 93449
- Usable with smart home gateways that have a Zigbee interface
- Can be controlled with the Smart Home Zigbee remote control
- Can still be switched on and off with the light switch
- Mesh-capable: range increases from product to product
- Set of 3 lights incl. LED module
- Color temperatur: 2700K - Warm white
- Very flat – can also be mounted in small cavities of only 30 mm depth
- For 230 V direct connection
| Dimension | |
|---|---|
| Diameter | 84 mm |
| Dimensions (Height x Width x Depth) | H: 28 mm |
| Built-in diameter | 68 mm |
| Mounting depth | 45 mm |
| Depth of hollow wall | 30 mm |
| net weight | 809 g |
| Design and Material | |
|---|---|
| Form | round |
| Colour | Matt white |
| Material | Aluminium |
| Stainless | stainless alu |
| Energy consumption | |
|---|---|
| Energy efficiency (spectrum A-G) | G |
| Light Characteristics | |
|---|---|
| Nominal luminous flux | 470 lm |
| Beam angle | 100 ° |
| Colour temperature | Warm white, 2700 K |
| Lamp Features | |
|---|---|
| Inclusive lamp | yes |
| Component parts | 6 W |
| light source property | Light source integrated (non-replacable) |
| Incandescent Equivalent | 40 W |
| Compatible Smart Home technology | Zigbee |
| Base/Socket | Coin |
| Technique | LED |
| Adjustability | swivelling/tilting |
| Dimmable | No |
| Number of component parts | 3x |
| Replacable | 2 Lightsource is replaceable without damage the lighting fixture by electrician. |
| Voltage | 230 V |
| Voltage type | AC 50 Hz |
| Accessories | |
|---|---|
| Radio control included | no |
| Labelling | |
|---|---|
| WEEE-Reg.-No | DE 39236390 |
| Smart Home | |
|---|---|
| Protocol type | Zigbee 3.0 |
| Zigbee certification | Zigbee_inside (not certified) |
| Radio frequency | 2,4 GHz |
| Radio range (Open field) | 20 m |
| Compatible smart home systems | Amazon Echo Smart Speaker with Zigbee 3.0 interface|Philips Hue Bridge 2 and Pro (excluded Hue Entertainment) |
