Article-No.:
70634
MaxLED 500LED Strip
Single strip 1m RGBW
coated 12W 500lm/m RGBW+
coated 12W 500lm/m RGBW+
- Individual strips
- To extend the MaxLED basic set
- Coating protects against splashing water and dust
MaxLED 500 LED Strip Single strip 1m RGBW coated 12W 500lm/m RGBW+
MaxLED strips are so powerful that they can easily be used as room lighting. They are real highlights especially in profiles. Thanks to the atmospheric colour change function they create an individual living ambience – where anything is possible, ranging from uni-coloured continuous lighting to multi-coloured light effects. A diode in white (W) additionally provides for a warm white light. As a result there is no need to mix white shade from the red, green and blue (RGB) colours. Where required, you can extend your basic set with individual strips. When planning, please keep in mind the maximum length specified for the basic set, which must not be exceeded.
- Individual strips
- To extend the MaxLED basic set
- Coating protects against splashing water and dust
- In conjunction with a shrink-on sleeve, can also be used in wet rooms
- Can be shortened as required
- Simple plug-in system for easy installation
- Rear self-adhesive for simple installation
- Flexible material for installation on flat or arched base surfaces
- RGB colour change
- Color temperatur: 3000K - Warm white
- Energy-saving LED technology conserves up to 80% energy in comparison to conventional filament lamps
- Incl. 5-pin plug for easy connection of the strips
| Dimension | |
|---|---|
| Dimensions (Height x Width x Depth) | H: 3 x B: 12,5 mm |
| Length | 1 m |
| Shortenability Strips | 100 mm |
| Design and Material | |
|---|---|
| Colour | Silver |
| Material | Plastic |
| Installation | |
|---|---|
| Installation site (recommendation) | Universal |
| Connections | |
|---|---|
| Plug-and-socket connector | Plug-and-socket connector |
| Energy consumption | |
|---|---|
| Energy efficiency (LED Module) | G |
| Features | |
|---|---|
| Blinking | Blinking |
| Flashlight function | Flashlight function |
| Service life | |
|---|---|
| Lifetime | 30000 h |
| Light Characteristics | |
|---|---|
| Colour temperature | Warm white, 3000 K |
| Nominal luminous flux | 440 lm |
| Luminous flux LED module | 500 lm |
| Color rendering index | > 80 Ra |
| Beam angle | 120 ° |
| Colour change | coloured light with Tunable White function (RGBW), Tunable White |
| Lumens per metre | 500 lm/m |
| Lamp Features | |
|---|---|
| Dimmable | Yes |
| Inclusive lamp | yes |
| Lamp property | Leuchtmittel fest integriert |
| Incandescent Equivalent | 42 W |
| IP protection | IP44 |
| Protection class | Protection class III |
| Technique | LED |
| Component parts | 12 W |
| Number of component parts | 1x |
| Number of LED's per meter | 60 |
| Replacable | 3 Lightsource is not replaceable, the complete lighting must be replaced. |
| Power consumption | 12 W |
| Adjustability | fixed |
| Voltage | 24 V |
| Voltage type | DC |
| Accessories | |
|---|---|
| Radio control included | no |
| Labelling | |
|---|---|
| MM symbol | MM symbol |
| WEEE-Reg.-No | DE 39236390 |
