Article-No.:
70630
MaxLED 500LED Strip
Extension 1m Tunable White
coated 7W 550lm/m Tunable White
coated 7W 550lm/m Tunable White
- Individual strips
- To extend the MaxLED basic set
- Coating protects against splashing water and dust
MaxLED 500 LED Strip Extension 1m Tunable White coated 7W 550lm/m Tunable White
MaxLED strips are so powerful that they can easily be used as room lighting. They are real highlights especially in profiles. The light colour of the strips can be individually varied - from daylight white workplace light to a warm white relaxing light – using the intelligent white light control, Tunable White. Where required, you can extend your basic strip with individual strips. When planning, please keep in mind the maximum length specified for the basic set, which must not be exceeded.
- Individual strips
- To extend the MaxLED basic set
- Coating protects against splashing water and dust
- In conjunction with a shrink-on sleeve, can also be used in wet rooms
- Can be shortened as required
- Simple plug-in system for easy installation
- Rear self-adhesive for simple installation
- Flexible material for installation on flat or arched base surfaces
- With white-light control (Tunable White)
- Colour temperature: 3000 K - Warm white up to 6500 K - Daylight white
- Energy-saving LED technology conserves up to 80% energy in comparison to conventional filament lamps
- Incl. 5-pin plug for easy connection of the strips
| Dimension | |
|---|---|
| Dimensions (Height x Width x Depth) | H: 3 x B: 12,5 mm |
| Length | 1 m |
| Shortenability Strips | 100 mm |
| Design and Material | |
|---|---|
| Colour | Silver |
| Material | Plastic |
| Recycled material included | no |
| Installation | |
|---|---|
| Installation site (recommendation) | Universal |
| Connections | |
|---|---|
| Plug-and-socket connector | Plug-and-socket connector |
| Energy consumption | |
|---|---|
| Energy efficiency (LED Module) | G |
| Service life | |
|---|---|
| Lifetime | 30000 h |
| Light Characteristics | |
|---|---|
| Colour temperature to | 6500 K |
| Colour temperature | Warm white to Daylight white, 2700 K |
| Nominal luminous flux | 470 lm |
| Luminous flux LED module | 550 lm |
| Color rendering index | > 80 Ra |
| Beam angle | 120 ° |
| Colour change | Tunable White |
| Lumens per metre | 550 lm/m |
| Lamp Features | |
|---|---|
| Dimmable | Yes |
| Inclusive lamp | yes |
| Lamp property | Leuchtmittel fest integriert |
| IP protection | IP44 |
| Protection class | Protection class III |
| Technique | LED |
| Component parts | 7 W |
| Number of component parts | 1x |
| Number of LED's per meter | 60 |
| Replacable | 3 Lightsource is not replaceable, the complete lighting must be replaced. |
| Power consumption | 7 W |
| Adjustability | fixed |
| Voltage | 24 V |
| Voltage type | DC |
| Accessories | |
|---|---|
| Radio control included | no |
| Labelling | |
|---|---|
| MM symbol | MM symbol |
| WEEE-Reg.-No | DE 39236390 |
