Article-No.:
94294
LED Recessed luminaire
Nova Mini Coin Single Luminaire Swivelling
round 66mm 15° Coin 4W 310lm 230V 2700K Brushed iron
round 66mm 15° Coin 4W 310lm 230V 2700K Brushed iron
- Set of 1 luminaire incl. LED module
- Color temperatur: 2700K - Warm white
- swivelling
LED Recessed luminaire Nova Mini Coin Single Luminaire Swivelling round 66mm 15° Coin 4W 310lm 230V 2700K Brushed iron
The swivelling recessed luminaire Nova mini in the colour Brushed iron offers whole new possibilities, thanks to its reduced size. It is suitable for conservatories, spot lighting, bar counters and beam cladding. The unique 35 mm Coin is exchangeable, flat and can be linked unlimited times.
- Set of 1 luminaire incl. LED module
- Color temperatur: 2700K - Warm white
- swivelling
- For 230 V direct connection
| Dimension | |
|---|---|
| Depth of hollow wall | 35 mm, 35 mm |
| Total Mounting depth | 50 mm |
| Ø | 66 mm |
| Mounting hole | 55 mm |
| Form | round |
| Design and Material | |
|---|---|
| Colour | Brushed iron |
| Material | Aluminium |
| Energy consumption | |
|---|---|
| Energy consumption | 4 kWh_1000h |
| Energy efficiency | F |
| Service life | |
|---|---|
| Lifetime | 30000 h |
| Light Characteristics | |
|---|---|
| Colour temp. | 2700 K |
| color temp | Warm white |
| Beam angle | 38 ° |
| Usable luminous flux | 310 lm |
| Color rendering index | > 80 Ra |
| Colour consistency (SDCM) | 3 |
| Lamp Features | |
|---|---|
| Component parts | 4 W |
| Swivel range | 15 ° |
| Technique | LED |
| Socket | Coin |
| Inclusive lamp | yes |
| Incandescent Equivalent | 29 W |
| Adjustability | swivelling/tilting |
| Dimmable | No |
| IP protection | IP23 |
| Number of component parts | 1x |
| protection class | Protection class II |
| Replacable | 2 Lightsource is replaceable without damage the lighting fixture by electrician. |
| Power consumption | 4 W |
| Accessories | |
|---|---|
| Radio control included | no |
| Labelling | |
|---|---|
| MM symbol | MM symbol |
| WEEE-Reg.-No | DE 39236390 |
Downloads
- LED Module recessed luminaire
