Article-No.:
93417
LED Recessed luminaire
Cymbal Coin
round 77mm max. 10W dimmable Matt white
round 77mm max. 10W dimmable Matt white
LED Recessed luminaire Cymbal Coin round 77mm max. 10W dimmable Matt white
100% minimalist – the transparent material of the premium frameless recessed luminaire Cymbal makes it almost invisible when it is not lit. You can choose any lamp you want and the slightly offset base ensures glare-free illumination.
- Dimmable
- IP protection: IP44 splash-protected
- For 230 V direct connection
| Dimension | |
|---|---|
| Depth of hollow wall | 35 mm, 35 mm |
| Total Mounting depth | 50 mm |
| Dimensions (Height x Width x Depth) | H: 50 mm |
| Ø | 77 mm |
| Mounting hole | 70 mm |
| Form | round |
| Design and Material | |
|---|---|
| Colour | Matt white |
| Material | Plastic |
| Installation | |
|---|---|
| Installation site (recommendation) | Ceiling mounting |
| Energy consumption | |
|---|---|
| Energy efficiency (A to G) | G |
| Lamp Features | |
|---|---|
| Technique | Lamp without bulb |
| IP protection | IP20 |
| Dimmable | The luminaire is dimmable, and the dimming capability depends on the type of lamp and ballast used. |
| Inclusive lamp | no |
| Adjustability | fixed |
| Maximum wattage range | max. 10 W |
| Replacable | 1 Lightsource is replaceable without damage the lighting fixture by enduser. |
| Labelling | |
|---|---|
| WEEE-Reg.-No | DE 39236390 |
