Article-No.:
94846
LED Recessed floor luminaireSmart Home Zigbee 3.0
Floor
IP67 angular 110x110mm RGBW+ 4,9W 300lm 230V 120° Brushed iron Aluminium
IP67 angular 110x110mm RGBW+ 4,9W 300lm 230V 120° Brushed iron Aluminium
- Beam angle 120°
- Color temperatur: 2700K - Warm white - 6500K -Daylight white
- Recessed floor light for large area lighting
LED Recessed floor luminaire Smart Home Zigbee 3.0 Floor IP67 angular 110x110mm RGBW+ 4,9W 300lm 230V 120° Brushed iron Aluminium
The angular LED recessed floor luminaire has a diameter of 110 mm and 420 lumens. It has a colour control with Tunable White and RGBW, which makes it possible to adjust the colour temperature individually and continuously. The RGBW function offers a free choice of light colour. The luminaire can withstand loads of up to 500 kg and is rustproof, waterproof and dustproof, providing light in all weather conditions. It is seawater-resistant and made of brushed iron. The beam angle is 120°.
- Beam angle 120°
- Color temperatur: 2700K - Warm white - 6500K -Daylight white
- Recessed floor light for large area lighting
- Seawater-resistant luminaire for use by the coast
- IP Protection: IP67 - protected against temporary immersion
- RGBW offers a fluid colour selection, plus the tunable white function
- Max. load up to 500 kg
- Dimmable
| Dimension | |
|---|---|
| Dimensions (Height x Width x Depth) | H: 148 x B: 110 x T: 110 mm |
| Built-in diameter | 103 mm |
| Design and Material | |
|---|---|
| Form | angular |
| Colour | Brushed iron |
| Material | Aluminium |
| Stainless | stainless |
| Recycled material included | no |
| Energy consumption | |
|---|---|
| Energy efficiency (LED Module) | F |
| Service life | |
|---|---|
| Lifetime | 25000 h |
| Light Characteristics | |
|---|---|
| Colour temperature to | 6500 K |
| Colour temperature | Warm white to Daylight white, 2700 K |
| Nominal luminous flux | 300 lm |
| Luminous flux LED module | 420 lm |
| Color rendering index | > 80 Ra |
| Beam angle | 120 ° |
| Colour change | coloured light with Tunable White function (RGBW), Tunable White |
| Lamp Features | |
|---|---|
| Dimmable | Yes |
| Dim | with Smart Home |
| Inclusive lamp | yes |
| Lamp property | Leuchtmittel fest integriert |
| IP protection | IP67 |
| Protection class | Protection class I |
| Technique | LED |
| Component parts | 4,9 W |
| Number of component parts | 1x |
| Compatible Smart Home technology | Zigbee |
| Replacable | 2 Lightsource is replaceable without damage the lighting fixture by electrician. |
| Power consumption | 9 W |
| Adjustability | fixed |
| Voltage | 230 V |
| Voltage type | AC 50 Hz |
| Accessories | |
|---|---|
| Radio control included | no |
| Labelling | |
|---|---|
| WEEE-Reg.-No | DE 39236390 |
| Smart Home | |
|---|---|
| Protocol type | Zigbee 3.0 |
| Zigbee certification | Zigbee zertifiziert |
| Radio frequency | 2,4 GHz |
| Radio range (Open field) | 20 m |
