Article-No.:
92900
LED Recessed luminaire
Nova Plus 3-piece set Swivelling
IP65 round 93mm 30° GU10 3x7W 3x460lm 230V dimmable 2700K Brushed iron
IP65 round 93mm 30° GU10 3x7W 3x460lm 230V dimmable 2700K Brushed iron
- Set of 3 luminaires
- With swivelling spots for ideal illumination
- Incl. replaceable LED lamp
LED Recessed luminaire Nova Plus 3-piece set Swivelling IP65 round 93mm 30° GU10 3x7W 3x460lm 230V dimmable 2700K Brushed iron
The round Nova Plus recessed luminaires (3-piece set) in Brushed iron with a replaceable GU10 lamp are suitable for new installations, as well as for replacing existing installations. They can be installed in ceilings with a cavity of only 75 millimetres. Straightforward mounting with retaining springs means that the ceiling remains undamaged, even after repeated installation and removal. The dimming function lets you adjust the brightness according to your needs and emits a warm white work light and cosy mood lighting in one. Thanks to IP65 protection, the luminaire is specially protected against penetration by water jets, making it ideal for installation in wet rooms or outdoor areas.
- Set of 3 luminaires
- With swivelling spots for ideal illumination
- Incl. replaceable LED lamp
- Color temperatur: 2700K - Warm white
- The lamp can easily be fitted without a snap ring
- IP protection: IP65 – water jet-protected
- For 230 V direct connection
| Dimension | |
|---|---|
| Einbaudurchmesser | 83 mm |
| Mounting depth | 90 mm |
| Depth of hollow wall | 75 mm |
| Diameter | 93 mm |
| Design and Material | |
|---|---|
| stainless | stainless alu |
| Colour | Brushed iron |
| Material | Aluminium |
| Form | round |
| Installation | |
|---|---|
| Installation site (recommendation) | Ceiling mounting |
| Energy consumption | |
|---|---|
| Energy consumption | 7 kWh_1000h |
| Energy efficiency | G |
| Service life | |
|---|---|
| Lifetime | 15000 h |
| Light Characteristics | |
|---|---|
| Colour temp. | 2700 K |
| Beam angle | 36 ° |
| Nominal luminous flux | 460 lm |
| Color rendering index | > 80 Ra |
| color temp | Warm white |
| Colour consistency (SDCM) | 6 |
| Lamp Features | |
|---|---|
| Component parts | 7 W |
| Swivel range | 30 ° |
| Technique | LED |
| Base/Socket | GU10 |
| Inclusive lamp | yes |
| Incandescent Equivalent | 40 W |
| Adjustability | swivelling/tilting |
| Lamp property | Leuchtmittel enthalten und wechselbar |
| Dimmable | with dimmer R+C f.elect.trafos+230V bulbs |
| IP protection | IP65 ceiling mounting |
| Number of component parts | 3x |
| protection class | Protection class II |
| Replacable | 1 Lightsource is replaceable without damage the lighting fixture by enduser. |
| Voltage | 230 V |
| Voltage type | AC 50 Hz |
| Accessories | |
|---|---|
| Radio control included | no |
| Labelling | |
|---|---|
| MM symbol | MM symbol |
| WEEE-Reg.-No | DE 39236390 |
