Article-No.: 92963

LED Module recessed luminaire Tunable White Coin

round 50mm Coin 6W 470lm 230V dimmable Tunable White Opal

Rated luminous flux: 470lm

  • Usable with smart home gateways that have a Zigbee interface
  • can be controlled with the Smart Home Zigbee remote control
  • bidirectional data transfer

LED Module recessed luminaire Smart Home Zigbee Tunable White Coin round 50mm Coin 6W 470lm 230V dimmable Tunable White Opal

You want to use the innovative Coins in combination with your existing lighting installations? No problem! If you have already installed recessed spotlights for standard lamps with a diameter of 51 mm, you can simply switch over to the super flat and energy-saving LED modules. The old lamp is removed, the tunable white coin connected with quick clips and you are ready to go! Use the tunable white function to set the light colour to suit your needs: from daylight white working light to relaxing, warm white lighting. The luminaire is Zigbee-compatible. Zigbee is a radio transmission protocol that links up the devices of several manufacturers. This allows not only the centralised control of lighting; shutters, heating and alarm systems, for example, can also be integrated. To operate the control, you can choose between the Smart Friends Box, a gateway for the same standard by a different manufacturer, or a Smart Home Zigbee hand-held transmitter. Individual components can be addressed, or switched on and off in groups as lighting scenarios.
  • Usable with smart home gateways that have a Zigbee interface
  • can be controlled with the Smart Home Zigbee remote control
  • bidirectional data transfer
  • LED module with junction box, incl. double quick terminal to loop through
  • Can still be switched on and off with the light switch
  • for 230 V direct connection
  • efficient LED technology
  • Color temperatur: 2700K - Warm white - 6500K -Daylight white
Dimension
Dimensions (Height x Width x Depth) H: 35mm
Ø 50mm
Form round
Design and Material
Colour Opal
Installation
can be used with the following dimmers Paulmann SmartHome Zigbee Gent 500.67
Installation site (recommendation) Ceiling mounting
Energy consumption
energy efficiency (A to G) G
Energy consumption 6kWh_1000h
Service life
Lamp lumen maintenance factor 6000h 80%
luminous flux at the end of lamplife 70%
Number of switching cycles >= 15000
lifetime 30.000h
Rated life time 30000h
Light Characteristics
Color temp. 2700K
Color change Tunable White
Beam angle 100°
Useful luminous flux 470lm
color temp 2.700 - 6.500K
colour consistency <= 6 Step of the MacAdam ellipse
Color rendering index > 80Ra
Rated luminous flux (Lumen) 470lm
Lamp Features
Component parts 6W
Dimmable Yes
Compatible Smart Home technology Zigbee
Technique LED
Socket Coin
Incandescent Equivalent 39 W
Dim with Smart Home
Inclusive lamp
Number of component parts 1x
protection class protection class II
Radio frequency 2,4 GHz
Radio range 20m
Labelling
WEEE-Reg.-No DE 39236390
